Introduction
14
NT2S-SF127B-E
System Components:
- Unit with LCD display, Membrane keypad
- Installation Kit: Gasket, Two Mounting clamps
Note: User should order cables separately
Power Supply 5VDC
Voltage Rating 5 VDC
+ 10% from PLC
Approvals CE and cULus Class1 Div.2
Certified
Bezel IP65 Rated Keypad
Keypad PCB based Keypad With
Tactile Feedback Keys
Number Of Keys 20 keys
Display LCD Text Display
Display Type 2 lines of 16 characters
Backlit LCD
Communication
Number of Ports 1
Type CMOS port for connecting
to PLC
1
4
7
CLR
2
5
8
0
3
6
9
+/-
F1
F2
F3
F4
REG
DATA
Miscellaneous
Dimension 92.00 X 92.00 mm
Operating Temperature 0
0
C to 50
0
C
Storage Temperature -25
0
C to 80
0
C
Mounting Method Panel Mounting
Clock(RTC) Does not support RTC
Humidity 10% To 90% (Noncondensing)
Immunity to ESD Level 3 as per IEC1000-4-2
Immunity to Transients Level 3 as per IEC1000-4-4
Immunity to Radiated Level 3 as per IEC1000-4-3
RF
Emission EN55011 CISPRA
