Hardware
25
NT3S-ST123B-E / ST124B-E
Com2 Port
Port Type: DB9 Female
Pin Name Description
Number
1NCNC
2 232TXD Transmit 232
3 RXD Receive 232 / CMOS
4NCNC
5 GND Circuit Ground
6 VCC +5 VDC
7 CMOSTXD Transmit CMOS
8NCNC
9NCNC
NT3S-ST126B-E
Com1 and Com2 Ports
Port Type: DB9 Female
Pin Name Description
Number
1NCNC
2 232TXD Transmit 232
3 RXD Receive 232 / CMOS
4NCNC
5 GND Circuit Ground
6 VCC +5 VDC
7 CMOSTXD Transmit CMOS
8NCNC
9NCNC
