BU75RW/BU100RW/BU200RW/BU300RW
8
79
For more details, refer to the instruction manual included with the SNMP/Web card.
The most recent fi rmware can be downloaded from our homepage(http://www.omron.co.jp/ese/).
Visit our website for the latest information (http://www.omron.co.jp/ese/).
■
Description (features)
•
Direct connection between UPS and network
Inserting an SNMP/Web card (SC20G) into the UPS enables a LAN connection, allowing the
UPS to be controlled via computers with no serial port.
•
Remote UPS management
Using a commercially available SNMP manager or web browser, you can control the UPS via a
computer connected to the network.
•
Possible to make function settings for the UPS and SNMP/Web card via a computer on the net-
work UPS and SNMP/Web card (SC20G) parameter settings can be made via any SNMP man-
agement station or internet browser. (Functions that act as an SNMP agent can make settings
via Telnet and serial connection.)
•
Enhanced security functions
For HTTP and SNMP connections, access can be controlled for each IP.
•
Coordinated shutdown
Multiple UPS can coordinate with each other to perform shutdown.
•
Log function
* The UPS power status, battery status, etc. can be stored in the built-in fl ash memory.
* Compatible with SYSLOG.
•
Auto shutdown function
Shutdown is automatically performed when there is a power supply error or when a shutdown
has been scheduled. Scheduled operations (auto startup and auto shutdown) can be performed
over the network.
•
Equipped with UPS standard MIB (RFC1628) and proprietary MIB (swc mib)
•
Using JAVA applet to monitor the power supply status
The power supply status can be visually checked on a graph display.
■
Specifi cations
LAN port 10/100 Mbit
Network protocol SNMP, HTTP, APR, RARP, TFTP, ICMP
Other communication route Serial connection: asynchronous method (setting only)
Number of controllable computers 32 max. (including slave UPS when coordinated shutdown is enabled)
Support MIB
UPSMIB (RFC1628)
OMRON MIB
Other Equipped with real-time lock
Shutdown software-compatible OS
Windows NT 4.0, Windows 2000, Windows XP, Windows Server 2003
Red Hat Linux 7.2/7.3/8.0
Red Hat Enterprise Linux AS/ES/WS (Red Hat Linux Advanced Server
2.1)
Max OS X v10.3*/Server 10.3 (*1)
Max OS X v10.4*/Server 10.4
(*1) Compatible only with Macintosh computers equipped with PowerPC CPU.
Unix Solaris 10
8-2
SNMP/Web card outline
