Omron S82J Series User Manual

S82J
S82J
13
S82J-10024j
(100 W, 24-V Output)
M3.5 terminal
screw
170±112 max.
4.5
97±1
65±0.5
7
162±0.5
160±0.5
100±0.5
15
25±0.5
4.5
28±0.5
50±1
Three, M4
6.5
4.5 dia.
27.5
15
4.5 dia.
5
162±0.5
65±0.5
Two, M3
Two, M3
160±0.5
Mounting Holes
Side Mounting
Bottom Mounting
S82J-100jjj
(100 W, 5-/12-/15-V Output)
S82J-15024j (150 W)
198 (see note)
188
180±0.5
4 max.
4.5
97
50
4.5
89±0.5
35±0.5
25±0.5
55±0.3100±0.5
27.5±0.3
7±0.3
178±0.5 3±0.25
3±0.25
8.1
9.5
M4 x 8
Three, M4
(6 mm max. deep)
4.5 dia.
4.5 dia.
Mounting holes
(on both sides)
Note: Top terminal and connector models
are 188 mm wide.
15
Mounting Holes
(Surface Screw Mounting)
Side Mounting
Bottom Mounting
180±0.5
82±0.8
Two, M4
178±0.5
Two, M4
S82J-30024j (300 W)
Eight, M4 holes
(depth: 8 max.
on both sides)
Four, M4 holes (depth: 8 max.)
Nine, M4 terminal screws
Side
4 max.
(19)
Mounting Holes
(Surface Screw Mounting)
Side Mounting
Bottom Mounting
150±0.5
50±0.5
Four, 4.5 dia.
150±0.5
100±0.5
Four, 4.5 dia.
