Chapter 5: Technical Specifications
This chapter shows the dimensions of the SmartController EX motion controller, Front Panel,
and T20 pendant.
5.1 SmartController EX Motion Controller Dimensions
NOTE: The dimensions for the legacy CS and CX SmartController motion con-
trollers were the same as these.
328.9
86.0
4.4
186.5 12.1
189.1
Figure 5-1. SmartController EX Motion Controller Dimensions (Units in mm)
