2-4
H 3G3FV-B4185-CE/-B4220-CE/-B4300-CE/-B4450-CE
3G3HV-B4185-CE/-B4220-CE/-B4300-CE/-B4450-CE
D External Dimensions D Mounting Dimensions
Four, M6
Series Voltage class Model 3G3FV-/3G3HV-
Dimensions (mm)
H H1 D1
3G3FV 400-V
B4185-CE/B4220-CE 450 435 174.5
B4300-CE/B4370-CE/B4450-CE 625 610 175
3G3HV 400-V
B4185-CE/B4220-CE 450 435 174.5
B4300-CE/B4370-CE/B4450-CE 625 610 175
Installation Chapter 2
