3-2
Parameter
No. (Reg-
ister No.
(Hex))
Name Description Setting
range
Default
setting
Changes
during
opera-
tion
Memo
n01
(0101)
Parame-
ter
write-
prohibit
selec-
tion/
parame-
ter ini-
tializa-
tion
Used to prohibit parameters to be
written, sets parameters, or change
the monitor range of parameters.
Used to initialize parameters to
default values.
0: Sets or monitors parameter n01.
Parameters n02 through n79 can
be monitored only.
1: Sets or monitors parameters n01
through n79.
5: Operation commands can be ac-
cepted at any time (n01 to n79 can
be set or referenced). (See note.)
6: Clears the error log.
8: Initializes parameters to default
values in 2-wire sequence.
9: Initializes parameters to default
values in 3-wire sequence.
Note Operation commands will be ig-
nored in Program Mode (refer
to 2-1-2) when n01 is set to 0 or
1. Normally set n01 to 0 or 1.
0, 1, 6, 8,
9
1 No
n02
(0102)
Opera-
tion
com-
mand
selec-
tion
Used to select the input method for
the RUN and STOP commands in
remote mode.
0: The RUN and STOP/RESET Keys
on the Digital Operator are en-
abled.
1: Multi-function inputs through the
control circuit terminals in 2- or
3-wire sequence.
2: Operation commands via
RS-422A/485 communications are
enabled.
Note The RUN command only
through key sequences on the
Digital Operator is acceptable
in local mode.
0 to 2 0 No
List of Parameters Chapter 3
