n40
(0128)
Multi-func-
tion output
(MA/MB
C
13 Inverter
ready
ON: Inverter ready to op-
erate (with no fault de-
tected)
0 to 7,
10 to
18
1 No
(
and MC
output ter
14 Fault retry ON: Fault retry
output ter-
minals)
15 UV in prog-
ress
ON: Undervoltage being
monitored
16 Rotating in
reverse
direction
ON: Rotating in reverse
direction
17 Speed
search in
progress
ON: Speed search in
progress
18 Data output
via commu-
nications
The inverter operates
multi-function output ter-
minals independently.
n41
(0129)
Frequency
reference
gain
Used to the input characteristics of analog fre-
quency references.
Gain: The frequency of maximum analog input
(10 V or 20 mA) in percentage based on the
0 to
255
100 Yes
n42
(012A)
Frequency
reference
bias
(10
V
or
20
mA)
in
percentage
based
on
the
maximum frequency as 100%.
Bias: The frequency of minimum analog input
(0 V or 0 or 4 mA) in percentage based on the
maximum frequency as 100%.
–99 to
99
0 Yes
n43
(012B)
Analog fre-
quency
reference
time
Used to set the digital filter with a first-order
lag for analog frequency references to be in-
put.
0.00
to
2.00
0.10 No
n44
(012C)
Analog
monitor
output
Used to set the output frequency or current as
a monitored item.
0: Output frequency (10-V output at max. fre-
quency with n45 set to 1.00).
1: Output current (10-V output with Inverter
rated output current with n45 set to 1.00)
0, 1 0 No
n45
(012D)
Analog
monitor
output gain
Used to set the output characteristics of ana-
log monitor output.
0.00
to
2.00
1.00 Yes
