3-12
Param-
eter
No.
(Regis-
ter No.
(Hex))
MemoChanges
during
opera-
tion
Default
setting
Set-
ting
range
DescriptionName
n40
(0128)
Multi-func-
tion output
Used to select the functions of multi-function
output terminals.
0 to 7,
10 to
1 No
(0128)
p
(MA/MB
and MC
output ter-
minals)
Set
val-
ue
Function Description
0
18
minals)
0 Fault output ON: Fault output (with
protective function work-
ing)
1 Operation
in progress
ON: Operation in prog-
ress
2 Frequency
detection
ON: Frequency detection
(with frequency reference
coinciding with output fre-
quency)
3 Idling ON: Idling (at less than
min. output frequency)
4 Frequency
detection 1
ON: Output frequency y
frequency detection level
(n58)
5 Frequency
detection 2
ON: Output frequency x
frequency detection level
(n58)
6 Overtorque
being moni-
tored (NO-
contact out-
put)
Output if any of the fol-
lowing parameter condi-
tions is satisfied.
n59: Overtorque detec-
tion function selection
n60: Overtorque detec-
tion level
61 O d
7 Overture
being moni-
tored (NC-
contact out-
put)
n61: Overtorque detec-
tion time
NO contact: ON with
overtorque being
detected
NC contact: OFF with
overtorque being
detected
8
Not used ---
9
10 Alarm out-
put
ON: Alarm being de-
tected (Nonfatal error be-
ing detected)
11 Base block
in progress
Base block in progress
(in operation with output
shutoff)
12 RUN mode ON: Local mode (with the
Digital Operator)
List of Parameters Chapter 3
