Omron SYSMAC C200H Installation Guide

Appendix BSpecifications
169
High-density I/O Units (Special I/O Units) The dimensions shown below are for the High-density I/O Units clas-
sified as Special I/O Units.
130
34.5 100.5
Fujitsu’s Connector is Used
G79-jC Connecting Cable is Used
118
118
145
Approx. 163
Backplane Backplane
G79-jC
Connecting
Cable
Connecting
cable
Dimensions with Unit Mounted
Standard B7A Interface Unit
The dimensions shown below are for the B7A Interface Unit classified as Special I/O Units.
130
35
101
118
Backplane
