Appendix B
Specifications
The following figures and tables provide specifications for each Unit of the C200H. I/O Units may take on one of
three different shapes and are sometimes referred to as A-shape Units, B-shape Units, or E-shape Units. Group-2
High-density I/O Units take on one of two different shapes and are sometimes referred to as C-shape Units or
D-shape Units. Refer to the figures at the end of the I/O Unit specifications for the exact dimensions of these five
shapes of I/O Unit.
CPU Units and Power Supplies
General Specifications
Item C200H-CPU21-E/CPU31-E, PS221 C200H-CPU23-E, PS211
Supply Voltage 100 to 120/200 to 240 VAC selectable
50/60 Hz
24 VDC
Operating Voltage Range 85 to 132/170 to 264 VAC 20.4 to 26.4 VDC
Power Consumption 120 VA max. 40 W max.
Surge Current 30 A max. 30 A max.
Output Capacity CPU-21-E: 4.6 A 5 VDC (3.2 A supplied to I/O Units)
CPU-23-E: 3 A 5 VDC (1.6 A supplied to I/O Units)
CPU-31-E: 4.6 A 5 VDC (3.0 A supplied to I/O Units)
Expansion I/O Rack: 3 A 5 VDC (2.7 A supplied to I/O Units)
Fuse 2 A 250 V 5.2 dia. x 20 (MF51NR) 2 A 125 V 5.2 dia. x 20 (MF51NR)
24 VDC Output 0.3 A 24 VDC
+10%
/
–20%
None
Insulation Resistance* 20 MΩ between AC terminals and the GR
terminal at 500 VDC
See caution.
Dielectric Strength* 2,000 VAC 50/60 Hz for 1 minute between AC terminals and housing 500 VAC 50/60 Hz
for 1 minute between DC terminals and housing Leakage current: 10 mA max.
Noise Immunity 1,500 Vp-p, pulse width: 100 ns to 1 µs, rise time: 1 ns
Vibration Mechanical durability: 10 to 35 Hz, 1 mm double amplitude (24.5 m/s
2
) in X, Y, and Z
directions, for 2 hours each (When mounted on DIN track, 16.7 Hz, 1 mm double
amplitude (4.9 m/s
2
) in X, Y, and Z directions, for 1 hour each)
Malfunction durability: 2 to 55 Hz, 19.6 m/s
2
, in X, Y, and Z directions, for 20 minutes
each (When mounted on DIN track, 2 to 55 Hz, 2.94 m/s
2
, in X, Y, and Z directions, for 20
minutes each)
Shock 98 m/s
2
in X, Y, and Z directions, 3 times each
Ambient Temperature Operating: 0° to 55°C (0° to 45°C for Programming Console) Storage: –20° to 65°C
Humidity 35% to 85% (without condensation)
Atmosphere Must be free of the following:
• Corrosive gases
• Abrupt temperature changes
• Direct sunlight
• Dust, salt, or metal filings
• Water, oil, or chemicals
Grounding Less than 100 Ω
Enclosure Rating Mounted in a panel
Weight 6 kg max.
Caution *Internal components might be damaged if insulation resistance or dielectric strength tests for the
AC power supply are repeated many times with the LG and GR terminals connected. Do not con-
duct a dielectric strength test on the C200H-CPU23-E, PS211, RT002-P, or RT202 Units. The
power supply input line and internal circuit of the 24 VDC Power Supply are not isolated from each
other; do not conduct insulation resistance or dielectric strength tests. If an insulation resistance
test or dielectric strength test over 50 VDC is conducted, the Power Supply will be damaged.
