N300 WiFi Router (N300R) User Manual
Customizing Your Network Settings 4-13
May 2012
Wireless Repeating (Also Called WDS)
The N300R router can be used with a wireless access point (AP) to build large bridged wireless
networks. Wireless repeating is a type of Wireless Distribution System (WDS).
The following figure shows a wireless repeating scenario:
To set up a wireless network using WDS,
he following conditions must be met for both APs:
• Both APs must use the same SSID, wireless channel, and encryption mode (see “Choosing
Appropriate Wireless Security” on page 2-1 or “Using WPS Push Button Connect (Wi-Fi
Protected Setup)” on page 2-13).
• Both APs must be on the same LAN IP subnet. That is, all the AP LAN IP addresses are in the
same network.
• All LAN devices (wired and wireless computers) must be configured to operate in the same
LAN network address range as the APs.
• If you make changes in the Wireless Settings screen, click Apply so that they take effect.
Warning: If you use the wireless repeating function, your options for wireless security
are limited to None or WEP. For more information about wireless security, see
Chapter 2, “Safeguarding Your Network.”
Figure 4-7
Repeater AP
Base Station AP
To Next Page
