ONEAN X USER’S MANUAL
11
04
uSe and conFiguration oF the equiPMent
3. Make sure the four pins are not visible and be aware of the
positioning while inserting it. Only one way is possible according to its
geometry.
4. Once the Battery is inserted in the board, insert
the four pins to lock the Battery. If the pins do
not enter easily, please, press down on the
battery so the watertight seal is sufficiently
compressed.
5. Close the vent completely, turning it clock wise to assure watertightness.
6. In order to ease the extraction of the batteries, turn the vent one full
round counter-clockwise. Pull from the upper handle perpendicularelly
to extract the batteries.
7. Keep the vent always closed in any other moment
and do not turn it more than three full turns.
Battery
Compartment
Board
Connectors
Antenna´s LED
