ONEAN X USER’S MANUAL
6
02
Packing List
2. Packing LiSt
The following describes a list of the components included with the equipment
and a description of them.
2.1. onean X board
Construction with EPS core and laminated breglass
and epoxy full sandwich.
• Weight (without batteries): 23 kg / 50 lbs
• Length: 240 cm / 7´8”
• Width: 70 cm / 27.7”
• Thickness: 15 cm / 5.9”
• Volume: 150 L
2.2. onean X bag
• Semi rigid Onean Bag.
• Full bag inner padded reinforcement.
• Includes detachable wheels that ease
transporting.
2.3. 2 Jet unitS
• Nominal power: 10 kW
• Nominal voltage: 44,4 VDC
• Speed: 45 km/h
2.4. batterieS
Short circuit, overcharge and temperature
protection. Waterproof.
• Type: multicell Litio-Ion
• Weight: 14 kg / 30 lbs
• Max. electric discharge: 130 A
• Nominal capacity: 40.0 Ah
• Nominal voltage: 44.4 V
• IP68 Certied
2.5. chargerS
Over voltage protection. Thermal protection. Short
circuit protection. Reverse polarity protection.
Charging indicator.
• Input power: 220-230 VAC (*Also available 110
VAC)
• Charging current: 15 A
• Output voltage: 50,4 VDC
2.6. reMote controL
Watertight. Thrust display. Battery display.
Pressure sensor Drop. Induction charging.
• Frequency: 2.4 GHz
• Battery: LiPo 300 mAh
2.7 greaSe
Silicone grease (white) for battery connectors,
blue grease for mechanical maintenance.
