3124.6SCFH
csv=0.3432Volt
Enter:PressF1&F2atthesametime
PressF4toreturntonormalmode
Display10
Display11
Display12
Display13
Pulse=1234.5cnt
mA_420=234cnt
Display14
Elp=12.5HR
Stat(hex)=2800
Display15
Alarm=None
F‐5500V3.5d
Display16
Display17
MB_Sn=M23949234
BB_Sn=M23945524
Display18
MTR_Sn=N12345
SNS_Sn=23456
Display19
TmpHi=0.0F
TmpLo=0.0F
F2KeyF1Key
F3&F4pressedatthesametimewill
initiatea"Total"reset
Pwr_Cycl=24
Err_tot=0
FloHi=0.00SCFH
FloLo=0.00SCFH
ZRO=0.1
11451 Belcher Road South, Largo, FL 33773 • USA • Tel +1 (727) 447-6140 • Fax +1 (727) 442-5699 • sales@onicon.com
F-5500 Thermal Mass Flow Meter Manual 06/17 - 2030 / 107023 Page 11
Model F-5500
INTRODUCTION
Introduction: Menu Trees
Engineering Display
Fig. 1.7: F-5500 Menu Tree - Engineering Display
