Onkyo A-9070 Service Manual

A-9070
EXPLODED VIEWS-1
A
1
2
3
4
5
B C D E F G H
Refer to
EXPLODED VIEWS-2
Refer to
EXPLODED VIEWS-3
A061
x 3 pcs.
A061
x 3 pcs.
A061
x 2 pcs.
A061
x 15 pcs.
A200
x 2 pcs.
A060
A051
x 4 pcs.
A021
x 2 pcs.
P109
x 2 pcs.
A038
x 2 pcs.
A043
x 4 pcs.
A030
x 4 pcs.
A017
x 2 pcs.
A014
x 2 pcs.
A075
x 2 pcs.
A052
x 2 pcs.
A010
x 3 pcs.
A039
x 2 pcs.
A028
x 4 pcs.
A028
x 4 pcs.
A026
x 4 pcs.
A026
x 4 pcs.
A034
x 4 pcs.
A065
x 3 pcs.
A042
x 6 pcs.
A042
x 6 pcs.
A042
x 6 pcs.
A039
x 4 pcs.
A064
x 4 pcs.
A027
x 7 pcs.
A065
x 2 pcs.
A215
x 4 pcs.
A042
x 14 pcs.
A217
x 11 pcs.
A051
x 3 pcs.
A061
x 6 pcs.
A061
x 2 pcs.
P9001A
P9001C
D9505
D9507
D9506
D9508
A033
x 2 pcs.
U0013
U0028
U004
U0026
U00210
U0035
U0012
U0032
U0031
U0030
U0034
U0033
A048
A049
A037
A020
A023
A022
A050
A073
A072
A007
A009
T9501
A006
A019
A008
A211
A019
A010
A005
A069
A214

Onkyo A-9070 Specifications

General

Damping factor	130
Amplifier class	-
Input sensitivity	150 mV
Audio output channels	2.0 channels
Peak power per channel	140 W
Signal-to-Noise Ratio (SNR)	107 dB
Total Harmonic Distortion (THD)	0.006 %
Dynamic power per channel (3 Ohm)	230 W
Dynamic power per channel (4 Ohm)	180 W
Dynamic power per channel (8 Ohm)	100 W
AC (power) in	Yes
Headphone connectivity	6.3 mm
Speakers connectivity type	RCA
Purpose	Home
Product color	Black
Volume control	Rotary
Cables included	AC
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	290 W

Weight and Dimensions

Depth	431 mm
Width	435 mm
Height	174.5 mm
Weight	18100 g
