Onkyo A-9070 Service Manual

A-9000R / 9070
EXPLODED VIEWS-3
A-9000R / 9070
<Fig-2>
Q6521A
Q6523A
Q6525A
Q6527A
A032
x 2 pcs.
A012
x 8 pcs.
A012
x 8 pcs.
A013
x 4 pcs.
A013
x 4 pcs.
A032
x 2 pcs.
A032
x 2 pcs.
A062
x 4 pcs.
Q6528A
Q6526A
Q6524A
Q6522A
A034
x 4 pcs.
A032
x 5 pcs.
U0039
A032
x 5 pcs.
U0014
U00310
A032
x 2 pcs.
A034
x 4 pcs.
Q6529A
Q6531A
Q6533A
Q6535A
Q6536A
Q6534A
Q6532A
Q6530A
A034
x 4 pcs.
U0015
A062
x 4 pcs.
A034
x 4 pcs.
A201
A011
A011
A015
A067
A201
A067
A201
A016
U0010
U0011
U0038
U0037
A067
A015
A201
A016
A067
Q6521
Q6523
Q6525
Q6527
Q6528
Q6526
Q6524
Q6522
Q6529
Q6536
Q6534
Q6532
Q6530
Q6531
Q6533
Q6535

Onkyo A-9070 Specifications

General

Damping factor	130
Amplifier class	-
Input sensitivity	150 mV
Audio output channels	2.0 channels
Peak power per channel	140 W
Signal-to-Noise Ratio (SNR)	107 dB
Total Harmonic Distortion (THD)	0.006 %
Dynamic power per channel (3 Ohm)	230 W
Dynamic power per channel (4 Ohm)	180 W
Dynamic power per channel (8 Ohm)	100 W
AC (power) in	Yes
Headphone connectivity	6.3 mm
Speakers connectivity type	RCA
Purpose	Home
Product color	Black
Volume control	Rotary
Cables included	AC
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	290 W

Weight and Dimensions

Depth	431 mm
Width	435 mm
Height	174.5 mm
Weight	18100 g
