Onkyo A-933 Service Manual

1/46 PAGE
A-933
<Note>
Parts marked by "NSP" are generally unavailable because
they are not in our Master Spare Parts List.
<Notes>
(S) : Silver model
(B) : Black model
[U] : Made in Japan
[M] : Made in Malaysia
EXPLODED VIEW PARTS LIST
REF. NO. PART NAME DESCRIPTION Q'TY PART NO REMARKS
EV
A001 F BRACKET (AS) 1 27111401 (S)
EV
A001 F BRACKET (AS) 1 27111437 (B)
EV
A002 SCREW 3TTB+8B(CU)SR 29 801618
EV
A003 SPACER t0.5 x 8 x 3.2 2 27270438
EV
A005 SCREW 3P+10FN(3BC) 2 82143010GR
EV
A007 KNOB (POW) 1 28326285 (S)
EV
A007 KNOB (POW) (B) 1 28326454 (B)
EV
A021 CHASSIS --- 1 --- NSP
EV
A022 LEG AS 4 27175408A (S)
EV
A022 LEG AS (B) 4 27175429 (B)
EV
A024 SCREW 3TTB+8B(3BC) 15 838430088GR
EV
A025 RETAINER (PC) 2 27141964
EV
A027 SHLD PLT (POW) 1 27150499
EV
A029 BRACKET (T) 1 27130978
EV
A032 SCREW 4TTC+8C(3BC) 8 830440089GR
EV
A033 HOLDER KGLS-6S 2 27190011
EV
A037 TAPE TAPE(CLOTH-16U) (1) 29110083
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.

Onkyo A-933 Specifications

General

Frequency range	10 - 60000 Hz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Product color	Black
Dimensions (WxDxH)	275 x 103 x 328 mm
Power requirements	AC 220-240 V, 50 Hz
Power consumption (standby)	0.9 W
Power consumption (typical)	100 W

Weight and Dimensions

Weight	7500 g
