Onkyo A-933 Service Manual

5/46 PAGE
EV
U06 HEADPHONE JACK PC board ass'y NAETC-8503-1 1 1B057503-1
EV
U08 MICROPROCESSOR PC board ass'y NADG-8505-1B 1 1B057505-1B
EV
U09 POWER SUPPLY PC board ass'y NAPS-8506-1B 1 1B057506-1B
EV
U10 OUTLET PC board ass'y NAPS-8507-1B 1 1B057507-1B
EV
U11 POWER SWITCH PC board ass'y NASW-8508-1B 1 1B057508-1B
EV
U13 SWITCH PC board ass'y NAETC-8510-1B 1 1B057510-1B
EV
U14 SPACER PC board NAETC-8511-1B 1 1B057511-1B
A-933
PC BOARD PARTS LIST
PCB1
U01 POWER AMPLIFIER PC BOARD (NAAF-8496-1B)
PCB1
PCB1
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO REMARKS
PCB1
Q413 IC TC74AC14FT 1 22242217R2
PCB1
Q414 IC TC74AC14FT 1 22242217R2
PCB1
Q415 IC TC74AC00FT 1 22242244R2
PCB1
Q416 IC TC74AC00FT 1 22242244R2
PCB1
Q525 IC 78M09HF(NJM78M09FA) 1 222780095JRC
PCB1
Q526 IC 78L05(NJM78L05UA) 1 222780053R2JR
PCB1
Q529 IC 78L05(NJM78L05UA) 1 222780053R2JR
PCB1
Q530 IC 78L05(NJM78L05UA) 1 222780053R2JR
PCB1
Q536 IC 78M09HF(NJM78M09DL1A) 1 222780095R2JR
PCB1
Q613 IC M51957BFP 1 22241239R2
PCB1
Q401 TR HN3C51F-BL 1 2217185R2
PCB1
Q402 TR HN3C51F-BL 1 2217185R2
PCB1
Q403 TR 2SC2712-GR 1 2213145R2
PCB1
Q404 TR 2SC2712-GR 1 2213145R2
PCB1
Q405 TR HN3A51F 1 2217190R2
PCB1
Q406 TR HN3A51F 1 2217190R2
PCB1
Q407 TR HN3A51F 1 2217190R2
PCB1
Q408 TR HN3A51F 1 2217190R2

Onkyo A-933 Specifications

General

Frequency range	10 - 60000 Hz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Product color	Black
Dimensions (WxDxH)	275 x 103 x 328 mm
Power requirements	AC 220-240 V, 50 Hz
Power consumption (standby)	0.9 W
Power consumption (typical)	100 W

Weight and Dimensions

Weight	7500 g
