Onkyo A-933 Service Manual

4/46 PAGE
EV
F901 FUSE 3.15A-SE-EAK FUSE 1 252076
!
EV
F901C FUSE LABEL T3.15AL250V 1 29362779
!
EV
F902 FUSE 2A-SE-EAK FUSE 1 252074
!
EV
P201A SHORT PIN YKV11-0435N 2 25056583
EV
P312 HOLDER (CRAMP) UA-0 V0 1 27190608-1
EV
P701 FFC NCFC5-153012 1 2045153012
EV
P901 AC CORD AS-CEE 1 253335HIT
!
EV
P901 or AC CORD AS-CEE (1) 253336VOL
!
EV
P901A CORE RFC-10 1 230986
!
EV
T901 P TRANS NPT-1521P 1 2301815
!
EV
T902 P TRANS NPT-1522P 1 2301817
!
EV
U01 POWER AMPLIFIER PC board ass'y NAAF-8496-1B 1 1B057596-1B
EV
U02 PRE-AMPLIFIER PC board ass'y NAAF-8499-1 & 1 1B057599-1
EV
--- --- NAAF-8500-1 --- ---
EV
<Note>
EV
Ref No. : U02 ---> PRE-AMPLIFIER PC board = NAAF-8294-1 + NAAF-8500-1
EV
U04 VOLUME PC board ass'y NAETC-8501-1 & 1 1B057501-1
EV
--- --- NAETC-8502-1 --- ---
EV
<Note>
EV
Ref No. : U04 ---> VOLUME PC board = NAETC-8501-1 + NAETC-8502-1

Onkyo A-933 Specifications

General

Frequency range	10 - 60000 Hz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Product color	Black
Dimensions (WxDxH)	275 x 103 x 328 mm
Power requirements	AC 220-240 V, 50 Hz
Power consumption (standby)	0.9 W
Power consumption (typical)	100 W

Weight and Dimensions

Weight	7500 g
