Onkyo A-933 Service Manual

36/46 PAGE
PCB2
J216 JMP WIRE TA100 1 --- NSP
PCB2
J221 PVC 1007#24 .2/7HAN 1 --- NSP
PCB2
J301 JMP WIRE TA125 1 --- NSP
PCB2
J302 JMP WIRE TA125 1 --- NSP
PCB2
J303 JMP WIRE TA125 1 --- NSP
PCB2
J305 JMP WIRE TA125 1 --- NSP
PCB2
J306 JMP WIRE TA125 1 --- NSP
PCB2
J307 JMP WIRE TA150 1 --- NSP
PCB2
JL302 JUMPER LEAD JL5 450 B 1 --- NSP
PCB2
JL302A WIRE HOL NSCT-5P876 1 25051089
PCB2
JL302B WIRE TRAP NPLG-5P588 1 25055626
PCB2
JL501 JUMPER LEAD JL9 150 B 1 --- NSP
PCB2
JL501A WIRE HOL NSCT-9P880 1 25051093
PCB3
U08 MICROPROCESSOR PC BOARD (NADG-8505-1B)
PCB3
U09 POWER SUPPLY PC BOARD (NAPS-8506-1B)
PCB3
U10 OUTLET PC BOARD (NAPS-8507-1B)
PCB3
U11 POWER SWITCH PC BOARD (NASW-8508-1B)
PCB3
U13 SWITCH PC BOARD (NAETC-8510-1B)

Onkyo A-933 Specifications

General

Frequency range	10 - 60000 Hz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Product color	Black
Dimensions (WxDxH)	275 x 103 x 328 mm
Power requirements	AC 220-240 V, 50 Hz
Power consumption (standby)	0.9 W
Power consumption (typical)	100 W

Weight and Dimensions

Weight	7500 g
