Onkyo A-933 Service Manual

37/46 PAGE
PCB3
PCB3
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO REMARKS
PCB3
U701 REMO SENS GP1UM281XKVFH=16MM 1 241361
PCB3
Q701 IC MPD780022AGC-166-8BS 1 22242259R3
PCB3
Q704 IC TA7291S 1 22240239
PCB3
Q731 IC MPC29M05HF 1 22278005ENE
PCB3
Q921 IC S-80127CNMC-JKM-T2 1 22241642R2
PCB3
Q702 TR RN1404 1 2214490R2
PCB3
Q703 TR RN2403 1 2214540R2
PCB3
Q705 TR RN1402 1 2214470R2
PCB3
Q706 TR RN1402 1 2214470R2
PCB3
Q707 TR RN1402 1 2214470R2
PCB3
Q708 TR RN1402 1 2214470R2
PCB3
Q709 TR RN1402 1 2214470R2
PCB3
Q710 TR RN1402 1 2214470R2
PCB3
Q711 TR RN2402 1 2214530R2
PCB3
Q712 TR RN2402 1 2214530R2
PCB3
Q713 TR 2SC2712-GR 1 2213145R2
PCB3
Q714 TR RN2402 1 2214530R2
PCB3
Q715 TR RN2402 1 2214530R2
PCB3
Q716 TR RN1402 1 2214470R2
PCB3
Q717 TR 2SC2712-GR 1 2213145R2
PCB3
Q901 TR RN1404 1 2214490R2
PCB3
Q902 TR 2SC1740S-R 1 2213284
PCB3
Q903 TR RN1404 1 2214490R2
PCB3
Q904 TR 2SC1740S-R 1 2213284
PCB3
D701 C-DIODE 1SS352 1 223234R2
PCB3
D701 or C-DIODE 1SS355 (1) 223269R2
PCB3
D702 C-DIODE 1SS352 1 223234R2
PCB3
D702 or C-DIODE 1SS355 (1) 223269R2
PCB3
D703 C-DIODE 1SS352 1 223234R2
PCB3
D703 or C-DIODE 1SS355 (1) 223269R2

Onkyo A-933 Specifications

General

Frequency range	10 - 60000 Hz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Product color	Black
Dimensions (WxDxH)	275 x 103 x 328 mm
Power requirements	AC 220-240 V, 50 Hz
Power consumption (standby)	0.9 W
Power consumption (typical)	100 W

Weight and Dimensions

Weight	7500 g
