Onkyo A-933 Service Manual

35/46 PAGE
PCB2
P206 ST JACK HSJ1406-01-020 1 25045835
PCB2
P207 ST JACK HSJ1406-01-020 1 25045835
PCB2
P208 ST JACK HSJ1406-01-020 1 25045835
PCB2
P209 ST JACK HSJ1406-01-020 1 25045835
PCB2
P212A PLUG NPLG-3P84 1 25055100
PCB2
P213A PLUG NPLG-2P149 1 25055165
PCB2
P251 BUS BAR BBL15 1 27141869
PCB2
P301A SOCKET AS NSAS-22P1528 1 2009990967UL
PCB2
P301B PLUG NPLG-11P125 1 25055141
PCB2
P310 CRIMP AS CRIMP AS 1 2061712140UL
PCB2
P311 HOLDER (CRAMP) UA-0 V0 1 27190608-1
PCB2
P381 JACK YKB26-5153 1 25045385
PCB2
P382 CRIMP AS CRIMP AS 1 2061713100UL
PCB2
P401A PLUG NPLG-4P118 1 25055134
PCB2
P701B SOCKET NSCT-15P2212 1 25052315
PCB2
P702A PLUG NPLG-3P131 1 25055147
PCB2
P705A PLUG NPLG-2P116 1 25055132
PCB2
J201 JMP WIRE TA100 1 --- NSP
PCB2
J202 JMP WIRE TA100 1 --- NSP
PCB2
J203 JMP WIRE TA100 1 --- NSP
PCB2
J204 JMP WIRE TA100 1 --- NSP
PCB2
J205 JMP WIRE TA100 1 --- NSP
PCB2
J206 JMP WIRE TA100 1 --- NSP
PCB2
J207 JMP WIRE TA100 1 --- NSP
PCB2
J208 JMP WIRE TA100 1 --- NSP
PCB2
J209 JMP WIRE TA100 1 --- NSP
PCB2
J210 JMP WIRE TA100 1 --- NSP
PCB2
J211 JMP WIRE TA100 1 --- NSP
PCB2
J212 JMP WIRE TA100 1 --- NSP
PCB2
J213 JMP WIRE TA100 1 --- NSP
PCB2
J214 JMP WIRE TA100 1 --- NSP
PCB2
J215 JMP WIRE TA100 1 --- NSP

Onkyo A-933 Specifications

General

Frequency range	10 - 60000 Hz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Product color	Black
Dimensions (WxDxH)	275 x 103 x 328 mm
Power requirements	AC 220-240 V, 50 Hz
Power consumption (standby)	0.9 W
Power consumption (typical)	100 W

Weight and Dimensions

Weight	7500 g
