Onkyo A-933 Service Manual

8/46 PAGE
PCB1
Q521D HEAT SINK 209 1 27160566
PCB1
Q521E HEAT SINK (215) 1 27160572
PCB1
Q521F SCREW 3TTB+8B(CU)SR 2 801618
PCB1
Q522A ISO SHEET M80 D-2 1 223037
PCB1
Q522B TR ACCY AC316A 1 223033
PCB1
Q522C SCREW 3TTB+8B(CU)SR 1 801618
PCB1
Q523A ISO SHEET M80 D-2 1 223037
PCB1
Q523B TR ACCY AC316A 1 223033
PCB1
Q523C SCREW 3TTB+8B(CU)SR 1 801618
PCB1
Q524A ISO SHEET M80 D-2 1 223037
PCB1
Q524B TR ACCY AC316A 1 223033
PCB1
Q524C SCREW 3TTB+8B(CU)SR 1 801618
PCB1
Q615 PHT CP TLP283-4 1 24120130R2
PCB1
Q671 PHT CP TLP521-1 1 24120032
PCB1
D401 ZENER D UDZS5.6B 1 224550560R2
PCB1
D402 ZENER D UDZS5.6B 1 224550560R2
PCB1
D403 C-DIODE 1SS352 1 223234R2
PCB1
D404 C-DIODE 1SS352 1 223234R2
PCB1
D405 C-DIODE 1SS352 1 223234R2

Onkyo A-933 Specifications

General

Frequency range	10 - 60000 Hz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Product color	Black
Dimensions (WxDxH)	275 x 103 x 328 mm
Power requirements	AC 220-240 V, 50 Hz
Power consumption (standby)	0.9 W
Power consumption (typical)	100 W

Weight and Dimensions

Weight	7500 g
