Onkyo A-933 Service Manual

10/46 PAGE
PCB1
D527 C-DIODE 1SS352 1 223234R2
PCB1
D528 C-DIODE 1SS352 1 223234R2
PCB1
D551 ZENER D UDZS5.6B 1 224550560R2
PCB1
D552 ZENER D UDZS5.6B 1 224550560R2
PCB1
D601 C-DIODE 1SS352 1 223234R2
PCB1
D602 C-DIODE 1SS352 1 223234R2
PCB1
D603 C-DIODE 1SS352 1 223234R2
PCB1
D604 C-DIODE 1SS352 1 223234R2
PCB1
L501 CHOKE COIL NCH-1536 1 231357K220
PCB1
L502 CHOKE COIL NCH-1536 1 231357K220
PCB1
L505 CHOKE COIL NCH-1537 1 231358
PCB1
L506 CHOKE COIL NCH-1537 1 231358
PCB1
C401 TF C ECQ-B50V-221K 1 374722215
PCB1
C402 TF C ECQ-B50V-221K 1 374722215
PCB1
C403 RFS C CE04W25V-47M(RFS) 1 395954707
PCB1
C404 RFS C CE04W25V-47M(RFS) 1 395954707
PCB1
C405 TF C ECQ-B50V-221K 1 374722215
PCB1
C406 TF C ECQ-B50V-221K 1 374722215
PCB1
C407 RFS C CE04W25V-47M(RFS) 1 395954707

Onkyo A-933 Specifications

General

Frequency range	10 - 60000 Hz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Product color	Black
Dimensions (WxDxH)	275 x 103 x 328 mm
Power requirements	AC 220-240 V, 50 Hz
Power consumption (standby)	0.9 W
Power consumption (typical)	100 W

Weight and Dimensions

Weight	7500 g
