11
Front & Rear Panels—Continued
k CD IN
This analog audio input is for connecting a CD
player’s analog audio output.
l TV/TAPE IN/OUT
This analog audio input and output are for connect-
ing a recorder with an analog audio input and output
(cassette, Mini Disc, etc.).
m GAME IN
Here you can connect a game console, etc. Input
jacks include composite video and analog audio.
n CBL/SAT IN
Here you can connect a cable/satellite receiver, set-
top box, etc. Input jacks include composite video
and analog audio.
o VCR/DVR IN/OUT
Here you can connect a VCR or DVR (digital video
recorder). Input and output jacks include composite
video and analog audio.
p DVD/BD IN
Here you can connect a DVD/BD player. Input
jacks include composite video and analog audio.
You can connect a DVD/BD player’s 2-channel ana-
log audio output.
q ZONE 2 LINE OUT L/R
This analog audio output can be connected to a line
input on an integrated amplifier in Zone 2. See
“Connecting Zone 2” on page 82.
r PRE OUT: SUBWOOFER
This analog audio outputs can be connected to a
powered subwoofer. The same signal is output from
each jack. You can connect the powered subwoofer
with two SUBWOOFER PREOUT jacks respec-
tively.
s FRONT HIGH L/R speakers
These terminals are for connecting the front high
L/R speakers.
The FRONT HIGH L/R terminal can be used with
front high speakers respectively, or used to connect
the speakers in Zone 2.
See “Connecting Zone 2” on page 82.
See pages 15-36 for connection information.
To Next Page
