Onkyo HT-RC160

27
Connecting the AV Receiver—Continued
See “Connecting Components with HDMI” on page 22 for HDMI connection information.
• With connection , you can listen to and record audio from a DVD/BD and listen in Zone 2.
• To enjoy Dolby Digital and DTS, use connection or . (To record or listen in Zone 2 as well, use and ,
or and .)
• If your DVD/BD player has main left and right outputs and multichannel left and right outputs, be sure to use
the main left and right outputs for connection .
Connecting a DVD/BD Player
Connection AV receiver Signal flow DVD/BD player
COMPONENT VIDEO IN 1 (DVD/BD) ⇐ Component video output
DVD/BD IN V ⇐ Composite video output
DVD/BD IN L/R ⇐ Analog audio L/R output
DIGITAL IN COAXIAL 1 (DVD/BD) ⇐ Digital coaxial output
DIGITAL IN OPTICAL 1 (GAME) ⇐ Digital optical output
Step 1: Video Connection
Choose a video connection that matches your DVD/BD player ( or ), and then make the connection.
You must connect the AV receiver to your TV via the same type of connection.
A B
Step 2: Audio Connection
Choose an audio connection that matches your DVD/BD player ( , , or ), and then make the connection.
a b c
a
b c a b
a c
a
A
B
a
b
c
YCOAXIAL
OUT
PB
COMPONENT VIDEO OUT
P
R AUDIO
OUT
VIDEO
OUT
LR
OPTICAL
OUT
b
c
A
B
B
a
DVD/BD player
Connect one or the other
Connection must be assigned (see page 41)
c
