SCHEMATIC DIAGRAM 4-1
Power supply and Video section
U14
Q141
TC7WU04FU
GND4
1
63
72
5
VCC 8
E901
Q131
TC7WU04FU
GND4
1
63
72
5
VCC 8
P131
L121
022M
L122
470M
P122A
P253A TO NAVD-7173 (SCHEMATIC 5)
P702B TO NAAR-7171 (SCHEMATIC 3)
Q210
RN2402
Q209
RN2402
U121
TORX179
U122
TORX179
U123
TORX179
A LENT, E POUR UNE PROTECTION PERMANENTE,N'UTILISER
INDIQUE LA QU LE PRESENT SYMBOL EST APPOSE.
QUE DES FUSIBLES DE MEME TYPE. CE DARNIER EST
CE SYMBOLE INDIQUE QUE LE FUSIBLE UTLISE EST
HAZARD,REPLACE WITH SAME TYPE FUSE. FOR FUSE
THIS SYMBOL LOCATED NEAR THE FUSE INDICATES
FOR CONTINUED PROTECTION AGAINST FIRE FUSE
THAT THE FUSE USED IS SLOW OPERATING TYPE
RATING REFER TO THE MAKING ADJACENT TO THE SYMBOL.
VA
ET CALIBRATION COMME INDIQUE.
D'INCENDIE, REMPLACER UNIQUEMENT
PERMANENTE CONTRE LES RISQUES
AFIN D'ASSURER UNE PROTECTION
PAR UN FUSIBLE DE MEME TYPE
ATTENTIION
VA
AGAINST FIRE HAZARD, REPLACE
FOR CONTINUED PROTECTION
AND RATING INDICATED.
ONLY WITH FUSE OF SAME TYPE
CAUTION
Q211
RN1402
Y
Y
YC
C
C
P202
YC
C Y
P201
Q205
RN1444-A
Q201
RN1444-A
Q206
RN1444-A
Q202
RN1444-A
5
6
7
8
NJM2246M
5
6
7
8
Q207
2SA1162-GR
Q203
2SA1162-GR
Q208
2SA1162-GR
Q204
2SA1162-GR
JL121A
JL121B
JL931B
Q921
2SC1740S-R
R150 000J
R144
150K
R147
150K
R141
150K
R142
100K
R145 100K
R148
100K
R205 75
R206 75
R217 75
R218 75
R133
10K
R132
75
R131
000J
R901
3.3M
D-TYPE ONLY
R922
4.7K
R925
4.7K
R924 82 (1/2W)
R923
4.7K
R221 390
R222 390
R223 390
R224 390
R225 390
R226 390
R227 390
R228 390
R239 100K R220
100K
R229 390
R230 390
R231 390
R232 390
R233 390
R234 390
R235 390
R236 390
R214 75
R213 75
R202 75
R201 75
R215 100K
R216 100K
R203 100K
R204 100K
R209 75
R210 75
C121
47/6.3
C204 2.2/50
C210
2.2/50
C216 100/6.3
C214
100/6.3
C922 470/16
C208
470/6.3
C202
470/6.3
C206 2.2/50
D241
D242
D924 D922
D923 D921
D925
F901*
FUSE
P/G-TYPE
F902*
FUSE
J/D-TYPE
RL901
C141
104K
C142
104K
C143
104K
C144 104Z
C124
104Z
C123
104Z
C122
104Z
C241 104Z
C203 104Z
C209
104Z
C991
103M
/275VAC
C135
104K
C134
104Z
C242
104Z
C132
080D
C133 104Z
C131
101J
C923
104Z
C901
103M
/275VAC
C921
104Z
C215 104Z
C213
104Z
C207 104Z
C201
104Z
C205 104Z
S991
T902
NPT-1398
P901A
P901
+13S
S3GND
POWER
+13V2
VGND
VGND
VGND
VCTLA
VCTLB
VMUT
AC-H
MGND
AC-G
SYSIN
GND
SW_PO
+5V
RX3RX3
GND
RX1
+5V
RX2
GND
RX3
J TYPE D TYPE P TYPE G TYPE
F901 NONE NONE T630MAL250V T630MAL250V
F902 2A/125V 2A/125V NONE NONE
F931 2.5A/125V 2.5A/125V T2.5AL250V T2.5AL250V
NADG-7174
TO NAAR-7171 (SCHEMATIC 2)
DVD HD VIDEO2
(OPTICAL)
DIGITAL INPUTS
MJJ ONLY
MDD,MPP,MDT,MGT TYPE
VIDEO 1 OUT VIDEO 1 IN VIDEO 2 INDVD IN MONITOR OUT
VIDEO2
(COAXIAL)
DIGITAL INPUT
NAVD-7173
NAETC-7177
NAPS-7162
MJJ
ONLY
