Onkyo TX-NR3030(B)

TX-NR1030/3030/ PR-SC5530/ DTR-60.6/70.6/ DHC-80.6
OPERATION CHECK-1
NOTATION ABOUT ENTERING TEST MODE BY PRESSING BUTTON
In this procedure, the following notations are used to simplify explanation of how to press button.
e.g.-1 [TV/CD] + [ON/STANDBY] → [BD/DVD]
This means "While holding down TV/CD button, press ON/STANDBY button then release both buttons and then press
BD/DVD button".
e.g.-2 [DISPLAY] + [ON/STANDBY] *2 → [DIMMER]
This means "While holding down DISPLAY button, press ON/STANDBY button twice then release both buttons and then press
DIMMER button".
INITIAL SETTING FOR SHIPPING
Initialization of memories.
Do the following operation.
Unplug the power cord from AVR after the FL tube displays "Clear" and AVR goes standby.
[CBL/SAT] + [ON/STANDBY]
CONFIRMATION OF F/W VERSION
to display MMPU version.
to display another F/W version.
<NOTE>
It cannot enter a test mode immediately after power supply ON, please press the Setup key.
1. [DISPLAY] + [ON/STANDBY]
Do the following operation.
2. [TONE+]
M1.03/14307ALN
e.g.
CONFIRMATION OF MAIN CHECKSUM
MAIN Checksum can be confirmed the following operation.
[DISPLAY] + [ON/STANDBY] * 2 → [MEMORY]
Temperature and output voltage can be confirmed the following operation.
CONFIRMATION OF OUTPUT VOLTAGE AND THERMAL SENSOR
[DISPLAY] + [ON/STANDBY] * 2 → [TONE]
e.g.
001 042 F:x S:H
Amplifier power
Supply voltage condition
H : High-B
L : Low-B
Temperature
of thermal sensor
Voltage
of VOLH port
FAN speed
x: Stop
L: Low speed
H: High speed
e.g.
>ONKYO@
Main:
1.05/14X07AM
DSP 1st/NET:
1.03/14X08AMA
DSP 2nd
1.01/14930AMA
Video:
1.01/14X06AM
VSP(KYOTOG2H):
1.01/14910AEO
OSD(Sparta):
1.00/14219AM
Rogue(TX)
1.02/14730A
Rogue(RX)
1.01/14730A
>Integra@
Main:
1.05/14X07AM
DSP 1st/NET:
1.03/14X08AMA
DSP 2nd
1.01/14930AMA
Video:
1.01/14X06AM
VSP(KYOTOG2H):
1.01/14910AEI
OSD(Sparta):
1.00/14219AM
Rogue(TX)
1.02/14730A
Rogue(RX)
1.01/14730A
VS100:
1.30.72.1
Main
DSP 1st/NET
DSP 2nd
HDMI/VIDEO
VSP
OSD
HDCP TX
HDCP RX
Main
DSP 1st/NET
DSP 2nd
HDMI/VIDEO
VSP
OSD
HDCP TX
HDCP RX
HDBase-T
