TX-NR1030/3030/ DTR-60.6/70.6
ADJUSTMENT PROCEDURE-2
ADJUSTMENT OF IDLING CURRENT
Top
RW
C
RSBRRHSR
L
LW
SL
LH
SBL
R6040 R6045 R6047 R6043 R6049
R6360 R6046R6048R6044 R6041R6042
P6071P6076P6078P6072P6080 P6074 P6070 P6079P6077P6075 P6073
Power Amp. Block
RW
C
RSBRRHSR
L
LW
SL
LH
SBL
Check point
Adjustment point
Check point and Adjustment point
TX-NR3030, DTR-70.6 only
<Note>
