Onkyo TX-NR3030(B)

1/94 PAGE
TX-NR3030(B)MDC
<Note>
Parts marked by "NSP" are generally unavailable because
<Notes>
they are not in our Master Spare Parts List.
(B) : Black color model
<MDC> : 120V
Canadian/USA/(Mexico) model
: NSP
TX-NR3030(B)MDC
EXPLODED VIEW PARTS LIST
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
Q6050 TRANSISTOR TTC0001(Q_T)TO3PN 1 2204130
Q6051 TRANSISTOR TTC0001(Q_T)TO3PN 1 2204130
Q6052 TRANSISTOR TTC0001(Q_T)TO3PN 1 2204130
Q6053 TRANSISTOR TTC0001(Q_T)TO3PN 1 2204130
Q6054 TRANSISTOR TTC0001(Q_T)TO3PN 1 2204130
Q6055 TRANSISTOR TTC0001(Q_T)TO3PN 1 2204130
Q6056 TRANSISTOR TTC0001(Q_T)TO3PN 1 2204130
Q6057 TRANSISTOR TTC0001(Q_T)TO3PN 1 2204130
Q6058 TRANSISTOR TTC0001(Q_T)TO3PN 1 2204130
Q6060 TRANSISTOR TTA0001(Q_T)TO3PN 1 2204120
Q6061 TRANSISTOR TTA0001(Q_T)TO3PN 1 2204120
Q6062 TRANSISTOR TTA0001(Q_T)TO3PN 1 2204120
Q6063 TRANSISTOR TTA0001(Q_T)TO3PN 1 2204120
Q6064 TRANSISTOR TTA0001(Q_T)TO3PN 1 2204120
Q6065 TRANSISTOR TTA0001(Q_T)TO3PN 1 2204120
Q6066 TRANSISTOR TTA0001(Q_T)TO3PN 1 2204120
Q6067 TRANSISTOR TTA0001(Q_T)TO3PN 1 2204120
Q6068 TRANSISTOR TTA0001(Q_T)TO3PN 1 2204120
Q6059 TRANSISTOR TTC0001(Q_T)TO3PN 1 2204130
Q6090 TRANSISTOR TTC0001(Q_T)TO3PN 1 2204130
Q6069 TRANSISTOR TTA0001(Q_T)TO3PN 1 2204120
Q6200 TRANSISTOR TTA0001(Q_T)TO3PN 1 2204120
[CHASSIS SCREW]
A049 P RIVET P-3055B-8L 2 880048
A153 BOTTOM LEG 4 27175452A
A155 CUSHION (LEG) 4 28141735
A215 P RIVET P-3055B-8L 2 880048
A341 LABEL (PT)ONK 1 29392650
A343A LABEL (E-CON) { 1} 29364978
A355 REAR PANEL TXNR3030DC 1 27124581
N
A391 LABEL (SP1) 1 29390790
A393 LABEL (SP2) 1 29390791
[CABINET]
A1601 COVER (B) (Bent) 1 28210040A
A1601 COVER (B) (Not Bent) 1 28210040AZ
A1701 LABEL (CAUTION) 1 29392531
A401 CLEAR PLATE TXNR1030 1 28192439A
A409 DECORATIVE FRAME (CP)B 1 27215388
A413 DECORATIVE FRAME (SEL)809_1009 1 27215386A
A421 BADGE 1 28135317
A423 BACK PLATE (B) 1 28133443
A427 KNOB (STBY)B 1 28326967
A433 PLATE (DOOR)1030(B)DC 1 27262920
A501 FRONT PANEL TXNR1030(B)DC 1 27213719
A502 FRONT BRACKET 828(B) 1 27111624B
A509 KNOB (CUR)AS BLACK 1 28326994C
A511 KNOB (ENTER) BLK 1 28326990
A513 KNOB (SEL)B 3 28326969B
A515 KNOB (INP)BLK 2 28326971A
A517 KNOB (INP)BLK3_4 2 28327057A
A519 KNOB (SETUP)BLK 2 28326973A
A521 KNOB (VOL)AS(B) 1 28327178A
A523 FACET (PURE) 1 28200056
A527 FACET (HDM) 1 28200057
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
