Onkyo TX-NR3030(B)

5/94 PAGE
TX-NR3030(B)MDC
PC BOARD PARTS LIST
U001
BAAF-1600-1B : NSP
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
1 D5009 ZENER DIODE DZ2J056M0L 1 224760560R2
1 D5009 or ZENER DIODE UDZS5.6B ( 1) 224550560R2
1 D5010 ZENER DIODE DZ2J056M0L 1 224760560R2
1 D5010 or ZENER DIODE UDZS5.6B ( 1) 224550560R2
1 D6704 ZENER DIODE DZ2J036M0L 1 224760360R2
1 D6901 CHIP TYPE DIODE DA2J10100 1 223303R2
1 D6902 CHIP TYPE DIODE DA2J10100 1 223303R2
1 D6902 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1 D6903 ZENER DIODE DZ2J036M0L 1 224760360R2
1 D6904 DIODE RL1N4003 1 22380260T
1 D6905 DIODE RL1N4003 1 22380260T
D6906 DIODE LN25XB60 1 22380345
1 D6907 CHIP TYPE DIODE DA2J10100 1 223303R2
1 D6907 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1 D6908 CHIP TYPE DIODE DA2J10100 1 223303R2
1 D6913 ZENER DIODE DZ2J036M0L 1 224760360R2
1 Q5009 TRANSISTOR 2SC2713-BL 1 2213136R2
1 Q5019 TRANSISTOR 2SC2713-BL 1 2213136R2
1 Q5029 TRANSISTOR 2SC2412K-R 1 2214653R2
1 Q5039 TRANSISTOR INA6006AP1-T111 1 2217980R2
1 Q5039 or TRANSISTOR 2SA1200-Y(2LONK_ZE) ( 1) 2217584R2
1 Q5049 TRANSISTOR INA6006AP1-T111 1 2217980R2
1 Q5049 or TRANSISTOR 2SA1200-Y(2LONK_ZE) ( 1) 2217584R2
1 Q5059 TRANSISTOR INA6006AP1-T111 1 2217980R2
1 Q5059 or TRANSISTOR 2SA1200-Y(2LONK_ZE) ( 1) 2217584R2
1 Q5069 TRANSISTOR INA6006AP1-T111 1 2217980R2
1 Q5069 or TRANSISTOR 2SA1200-Y(2LONK_ZE) ( 1) 2217584R2
1 Q5089 TRANSISTOR INC6006AP1-T111 1 2217990R2
1 Q5089 or TRANSISTOR 2SC2880-Y(2LONK_ZE) ( 1) 2217594R2
1 Q5099 TRANSISTOR INC6006AP1-T111 1 2217990R2
1 Q5099 or TRANSISTOR 2SC2880-Y(2LONK_ZE) ( 1) 2217594R2
1 Q5100 TRANSISTOR 2SC2713-BL 1 2213136R2
1 Q5110 TRANSISTOR 2SC2713-BL 1 2213136R2
1 Q5120 TRANSISTOR 2SC2412K-R 1 2214653R2
1 Q5130 TRANSISTOR INA6006AP1-T111 1 2217980R2
1 Q5130 or TRANSISTOR 2SA1200-Y(2LONK_ZE) ( 1) 2217584R2
1 Q5140 TRANSISTOR INA6006AP1-T111 1 2217980R2
1 Q5140 or TRANSISTOR 2SA1200-Y(2LONK_ZE) ( 1) 2217584R2
1 Q5150 TRANSISTOR INA6006AP1-T111 1 2217980R2
1 Q5150 or TRANSISTOR 2SA1200-Y(2LONK_ZE) ( 1) 2217584R2
1 Q5160 TRANSISTOR INA6006AP1-T111 1 2217980R2
1 Q5160 or TRANSISTOR 2SA1200-Y(2LONK_ZE) ( 1) 2217584R2
1 Q5170 TRANSISTOR INC6006AP1-T111 1 2217990R2
1 Q5170 or TRANSISTOR 2SC2880-Y(2LONK_ZE) ( 1) 2217594R2
1 Q5180 TRANSISTOR INC6006AP1-T111 1 2217990R2
1 Q5180 or TRANSISTOR 2SC2880-Y(2LONK_ZE) ( 1) 2217594R2
1 Q6019 TRANSISTOR 2SC2412K-R 1 2214653R2
1 Q6020 TRANSISTOR 2SC2412K-R 1 2214653R2
1 Q6039 TRANSISTOR INC6006AP1-T111 1 2217990R2
1 Q6039 or TRANSISTOR 2SC2880-Y(2LONK_ZE) ( 1) 2217594R2
1 Q6049 TRANSISTOR INA6006AP1-T111 1 2217980R2
1 Q6049 or TRANSISTOR 2SA1200-Y(2LONK_ZE) ( 1) 2217584R2
1 Q6050 TRANSISTOR INA6006AP1-T111 1 2217980R2
1 Q6050 or TRANSISTOR 2SA1200-Y(2LONK_ZE) ( 1) 2217584R2
1 Q6060 TRANSISTOR INC6006AP1-T111 1 2217990R2
1 Q6060 or TRANSISTOR 2SC2880-Y(2LONK_ZE) ( 1) 2217594R2
Q6109 TRANSISTOR TTA004B_Q(S 1 2218012
Q6109 or TRANSISTOR TTA-004(Q)TO126 ( 1) 2217442
Q6119 TRANSISTOR TTC004B_Q(S 1 2218022
Q6119 or TRANSISTOR TTC-004(Q)TO126 ( 1) 2217452
Q6120 TRANSISTOR TTC004B_Q(S 1 2218022
