Onkyo TX-NR3030(B)

15/94 PAGE
1 P6932A TERMINAL NTM-1P233(M1969) 1 25060302
P6940A PLUG NPLG-2P631 1 25055675
1 P6940B RETAINER (BUS-5) 1 27142311
N
1 P6940C RETAINER (BUS-5) 1 27142311
N
P6941A PLUG NPLG-2P631 1 25055675
1 P6941B RETAINER (BUS-6) 1 27142310
1 P6941C RETAINER (BUS-6) 1 27142310
P6942B PLUG NPLG-3P131 1 25055147
P6950B PLUG NPLG-3P350 1 25055367
P6951 PLUG NPLG-2P83 1 25055099
1 P6952 TRM-423(SCREW ) NEJITANSI ST3 1 25060495
P6960B PLUG NPLG-3P350 1 25055367
P6961 PLUG NPLG-2P83 1 25055099
1 P6962 TRM-423(SCREW ) NEJITANSI ST3 1 25060495
U003
BACLA-1607-1A : NSP
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
1 D5000 ZENER DIODE DZ2J056M0L 1 224760560R2
1 D5000 or ZENER DIODE UDZS5.6B ( 1) 224550560R2
1 D5001 ZENER DIODE DZ2J056M0L 1 224760560R2
1 D5001 or ZENER DIODE UDZS5.6B ( 1) 224550560R2
1 D5003 ZENER DIODE DZ2J056M0L 1 224760560R2
1 D5003 or ZENER DIODE UDZS5.6B ( 1) 224550560R2
1 D5004 ZENER DIODE DZ2J056M0L 1 224760560R2
1 D5004 or ZENER DIODE UDZS5.6B ( 1) 224550560R2
1 D5005 ZENER DIODE DZ2J056M0L 1 224760560R2
1 D5005 or ZENER DIODE UDZS5.6B ( 1) 224550560R2
1 D5006 ZENER DIODE DZ2J056M0L 1 224760560R2
1 D5006 or ZENER DIODE UDZS5.6B ( 1) 224550560R2
1 D5007 ZENER DIODE DZ2J056M0L 1 224760560R2
1 D5007 or ZENER DIODE UDZS5.6B ( 1) 224550560R2
1 D5008 ZENER DIODE DZ2J056M0L 1 224760560R2
1 D5008 or ZENER DIODE UDZS5.6B ( 1) 224550560R2
1 Q5000 TRANSISTOR 2SC2713-BL 1 2213136R2
1 Q5001 TRANSISTOR 2SC2713-BL 1 2213136R2
1 Q5003 TRANSISTOR 2SC2713-BL 1 2213136R2
1 Q5004 TRANSISTOR 2SC2713-BL 1 2213136R2
1 Q5005 TRANSISTOR 2SC2713-BL 1 2213136R2
1 Q5006 TRANSISTOR 2SC2713-BL 1 2213136R2
1 Q5007 TRANSISTOR 2SC2713-BL 1 2213136R2
1 Q5008 TRANSISTOR 2SC2713-BL 1 2213136R2
1 Q5010 TRANSISTOR 2SC2713-BL 1 2213136R2
1 Q5011 TRANSISTOR 2SC2713-BL 1 2213136R2
1 Q5013 TRANSISTOR 2SC2713-BL 1 2213136R2
1 Q5014 TRANSISTOR 2SC2713-BL 1 2213136R2
1 Q5015 TRANSISTOR 2SC2713-BL 1 2213136R2
1 Q5016 TRANSISTOR 2SC2713-BL 1 2213136R2
1 Q5017 TRANSISTOR 2SC2713-BL 1 2213136R2
1 Q5018 TRANSISTOR 2SC2713-BL 1 2213136R2
1 Q5020 TRANSISTOR 2SC2412K-R 1 2214653R2
1 Q5021 TRANSISTOR 2SC2412K-R 1 2214653R2
1 Q5023 TRANSISTOR 2SC2412K-R 1 2214653R2
1 Q5024 TRANSISTOR 2SC2412K-R 1 2214653R2
1 Q5025 TRANSISTOR 2SC2412K-R 1 2214653R2
1 Q5026 TRANSISTOR 2SC2412K-R 1 2214653R2
1 Q5027 TRANSISTOR 2SC2412K-R 1 2214653R2
1 Q5028 TRANSISTOR 2SC2412K-R 1 2214653R2
1 Q5030 TRANSISTOR INA6006AP1-T111 1 2217980R2
1 Q5030 or TRANSISTOR 2SA1200-Y(2LONK_ZE) ( 1) 2217584R2
1 Q5031 TRANSISTOR INA6006AP1-T111 1 2217980R2
1 Q5031 or TRANSISTOR 2SA1200-Y(2LONK_ZE) ( 1) 2217584R2
1 Q5033 TRANSISTOR INA6006AP1-T111 1 2217980R2
1 Q5033 or TRANSISTOR 2SA1200-Y(2LONK_ZE) ( 1) 2217584R2
