GeneralSpecifications
AmplifierSection
RatedOutputPower(FTC)(NorthAmerican)
With8ohmloads,bothchannelsdriven,at1kHz;rated140wattsper
channelminimumRMSpower,withnomorethan0.08%totalharmonic
distortionfrom250milliwattstoratedoutput.
SurroundModeOutputPower(＊)
(6ohms,1kHzTHD0.9%)200Wperchannel
＊Referenceoutputforeachspeakers.
Dependingonthesourceandthelisteningmodesettings,theremaybeno
soundoutput.
RatedOutputPower(IEC)(Others)
11ch×200Wat6ohms,1kHz,1chdrivenof1%THD
MaximumEffectiveOutputPower(JEITA)(AsianandAustralian)
11ch×320Wat4ohms,1kHz,1chdrivenof10%THD
DynamicPower(＊)
＊IEC60268Shorttermmaximumoutputpower
320W(3Ω,Front)
270W(4Ω,Front)
160W(8Ω,Front)
THD+N(TotalHarmonicDistortion+Noise)
0.04%(1kHz,100W)
InputSensitivityandImpedance(1kHz,100W/8Ω)
200mV/82kΩ(LINE(Unbalance))
3.5mV/47kΩ(PHONOMM)
RatedRCAOutputLevelandImpedance
1V/330Ω(PREOUT)
1V/330Ω(SUBWOOFERPREOUT)
200mV/1.2kΩ(ZONELINEOUT)
2V/1.2kΩ(ZONEPREOUT)
PhonoOverload
70mV(MM1kHz0.5%)
ToneControlCharacteristics
±10dB,100Hz(BASS)
±10dB,10kHz(TREBLE)
SignaltoNoiseRatio
108dB(IHFA,LINEIN,SPOUT)
90dB(IHFA,PHONOIN,SPOUT)
SpeakerImpedance
4Ω16Ω
HeadphoneOutputImpedance
