Onkyo TX-SR303E

25
Connecting Your Components—Continued
Connecting a VCR or DVD Recorder for Recording
Connection TX-SR303/303E Signal flow VCR/DVD recorder
VIDEO 1 OUT
⇒
Composite video input
VIDEO 1 OUT L/R
⇒
Audio L/R input
Connecting a Camcorder, Games Console, or Other Device
Connection TX-SR303/303E Signal flow Camcorder/console
VIDEO 3 IN
⇐
Composite video output
VIDEO 3 IN L/R
⇐
Analog audio L/R output
L
R
L
R
VIDEO 1
AUDIO
IN
VIDEO IN
VIDEO 1
Step 1: Make video connection .
Step 2: Make audio connection .
A
a
A
a
VCR,
DVD recorder
A
a
VIDEO OUT
VIDEO 3
IN
L
R
AUDIO
OUT
LR
VIDEO 3
IN
Step 1: Make video connection .
Step 2: Make audio connection .
A
a
A
a
Camcorder, games console,
etc.
A
a
