Onkyo TX-SR403

25
Connecting Your Components —Continued
Connecting a VCR or DVD Recorder for Recording
Connection TX-SR403/8340 Signal flow VCR/DVD recorder Picture quality
S VIDEO VIDEO 1 OUT
⇒
S-Video input
Better
VIDEO VIDEO 1 OUT
⇒
Composite video input Standard
VIDEO 1 OUT L/R
⇒
Audio L/R input
—
Connecting a Camcorder, Games Console, or Other Device
Connection TX-SR403/8340 Signal flow Camcorder/console
VIDEO 3 IN
⇐
Composite video output
VIDEO 3 IN L/R
⇐
Analog audio L/R output
L
R
L
R
VIDEO 1
AUDIO
IN
S VIDEO IN
VIDEO IN
VIDEO 1
VIDEO
S VIDEO
VIDEO 1
Step 1: Choose a video connection type ( or ) that matches the VCR/DVD recorder, and make the connection.
The video source that you want to record must be connected to the AV receiver with the same type of connection.
Step 2: Make audio connection
.
A B
a
A
B
a
VCR,
DVD recorder
A
B
a
VIDEO OUT
AUDIO
OUT
LR
VIDEO 3
IN
VIDEO 3
IN
L
R
Step 1: Make video connection .
Step 2: Make audio connection .
A
a
A
a
Camcorder, games console,
etc.
A
a
