Onkyo TX-SR500/E - Page 35

CIRCUIT NO. PART NO. DESCRIPTION
Resistors
R6040-R6044 5210258 N06HR1KBC,Trimming
R6070-R6074 415471014 100ohm+/-5%,1/4W,NF carbon
R6080-R6084 415470224 2.2ohm+/-5%,1/4W,NF carbon
R6090-R6094 415470224 2.2ohm+/-5%,1/4W,NF carbon
R6100-R6104 4800071, RSS2WK-0.22,
4500027 or MPC708-2WK-0.22 or
4000131 RGC22-0.22 OHMK,Cement
R6230-R6234 453630824 8.2ohm+/-5%,1W,Metal
R6850,R6851 443523914 390ohm+/-5%,1/2W,Metal oxide
Relays
RL6901,RL6902 25065561, NRL-1P5A-DC12-127,
25065508, NRL-1P10A-DC12-093,
25065515 or NRL-1P5A-DC12-096 or
25065526 NRL-1P5A-DC12-102
Fuse holders
F6901A,F6901B 25052133 NSCT-1P2031
F6902A,F6902B 25052133 NSCT-1P2031
Sockets
JL6402A 25051087 NSCT-3P874
JL6803A 25051109 NSCT-5P896
JL6804A 25051109 NSCT-5P896
JL6805A 25051108 NSCT-4P895
JL6951A 25051109 NSCT-5P896
JL6951B 25051109 NSCT-5P896
Plugs
P6000~P6004 25056010 NPLG-5P0960
P6011 25056014 NPLG-9P0964
P6080~P6084 25055038 NPLG-2P29
P6301 25055038 NPLG-2P29
P6931 25055711 NPLG-15P667
P931 25055701 NPLG-5P657
Clamp
P6801 260226 CP-2S
Bar
P6903 27141806 BBL25
Fuse labels
F6901C 29362800 T8AL250V <O>
CIRCUIT NO. PART NO. DESCRIPTION
Switch
S906 25035702 NPS-121-L665P <O>
POWER SWITCH PC BOARD (NASW-7418-1B/1C/1D/1E/1F)
CIRCUIT NO. PART NO.
DESCRIPTION
PRIMARY CIRCUIT PC BOARD (NAPS-7420-1A/1B/1C/1D/1E/1F)
Transistors
Q921 2215864, KTC3199-GR,
2212115, 2SC2458-GR,
2213284 or 2SC1740S-R or
2213285 2SC1740S-S
Diodes
D925 223163, 1SS133,
223205 or 1SS270A or
223222 WG713A
D921-D924 22380260 or RL1N4003 or
22380035 GP104003E
Power transformer
T902 2301381 NPT-1358D <D>
2301382 NPT-1358P <P/A>
2301383 NPT-1358DG <R/T/Q/A>
Capacitors
C901 3500196S RE275V-103M,IS
C902 3300030 DE1307E472M-KH,IS <O>
C922 394662217 220uF,35V,Elect.
Resistors
R901 4000206S or RD1/2SPH-3.3M or
431533355 RC1/2GFKUL-3.3M <D>
R924 443528204 82ohm+/-5%,1/2W,Metal oxide
CIRCUIT NO. PART NO. DESCRIPTION
Relays
25065561, NRL-1P5A-DC12-127,
RL901
25065508, NRL-1P10A-DC12-093,
25065515 or NRL-1P5A-DC12-096 or
25065526 NRL-1P5A-DC12-102
Switch
S902 25065437 NSS-22157P <R/T/Q>
25052115 NSCT-2P2013 <A>
Fuse holders
F901A,F901B 25052133 NSCT-1P2031<D/R/T/Q>
F902A,F902B 25052133 NSCT-1P2031<O>
F903A,F903B 25052133 NSCT-1P2031
Sockets
P902 25051571 NSCT-2P1358 <D>
25051572 NSCT-2P1359 <P>
25052381 NSCT-2P2278 <R>
25051572 NSCT-2P1359 <T/Q>
P931A 25051230 NSCT-5P1020
Plug
P901A 25055675 or NPLG-2P631 or
25056028 NPLG-2P0978
CIRCUIT NO. PART NO.
DESCRIPTION
TERMINAL PC BOARD (NAPS-7421-1A/1B/1C/1D/1E/1F)
JL6951B 25051109 NSCT-5P896,Socket
JL6952B 25051109 NSCT-5P896,Socket
CIRCUIT NO. PART NO.
DESCRIPTION
VIDEO TERMINAL PC BOARD (NAVD-7422-1A/1B/1C/1D/1E/1F)
ICs
Q203 22241759 LA7956
Q212,Q213 22241759 LA7956
Q281 222740046R2 74HCU04F
Transistors
Q201,Q202 2213631 or RN1241-A or
Q207,Q208 2213632 RN1241-B
Q204,Q209 2215995 or KTA1267-GR or
2213354 2SA933S-R
Q205,Q206 2215770 or KRA102M or
2213510 DTA114ES
Q210,Q211 2213631 or RN1241-A or
2213632 RN1241-B
Photo couplers
U281,U282 24120083, GP1FA550RZ,
24120086 or GP1FA551RZ or
24120095 TORX179
Coils
L281,L282 233454K220 NCH-1452 220K
L283 233454M022 NCH-1452 022M
NOTE: THE COMPONENTS IDENTIFIED BY MARK !
ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH
PART NUMBER SPECIFIED.
Note:
<D>: 120V model only
<P>: European model only
<T>: Worldwide model only
<Q>: Hongkong model only
<A>: Australian model only
<R>: Chinese model only
<O>: Except 120V model
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
TX-SR500/E
PRINTED CIRCUIT BOARD-PARTS LIST 4
35
