Onkyo TX-SR500/E - Exploded View Parts List

CAUTION: Replacement for transistor of mark *, if necessary
must be made from the same beta group (H
FE) as
the original type.
NOTE: THE COMPONENTS IDENTIFIED BY MARK !
ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH
PART NUMBER SPECIFIED.
Note:
<B>: Black model only
<G>: Golden model only
<S>: Silver model only
<D>: 120V model only
<P>: European model only
<T>: Worldwide model only
<K>: Korean model only
<A>: Australian model only
<R>: Chinese model only
<Q>: Hongkong model only
<O>: Except 120V model
REF.NO. PART NO. DESCRIPTION
1 27111268 Front bracket <B>
27111269 Front bracket <S>
27111270 Front bracket <G>
2 838130088 3TTB+8B,Self-tapping screw
3 82143010 3P+10FN(BC),Pan head screw
4 28325497A Knob,power <B>
28325499A Knob, power <G>
28325547A Knob, power <S>
5 27100416 Chassis
6 27190503A KGLS-8RF,Holder
7 27190813 KGPS-10RF,Holder
8 27190428A KGLS-10RF,Holder
9 830440089 4TTC+8C(BC),Self-tapping screw
10 880009 NRP-345,Plastic rivet
11 27300750 Bushing,cord
12 27160501 Heat sink
13 801433 3SMS8W.SW+14B(BC),Special screw
16 28184831 Top cover <B>
28184833 Top cover <S>
28184834 Top cover <G>
17 838430088
838930088
3TTB+8B(BC),Self-tapping screw <B>
3TTB+8B(UN),Self-tapping screw <G/S>
21 27175319B Leg
22 28141494 Cushion
23 838130088 3TTB+8B,Self-tapping screw
24 28325641 Knob, volume <B>
28325642 Knob, volume <S>
28325643 Knob, volume <G>
25 28191957 Clear plate <B>
28191958 Clear plate <G/S>
31 27122953A Rear panel <D>
27122954A Rear panel <P>
27122955A Rear panel <K>
27122956A Rear panel <T/Q>
27122957B Rear panel <R>
27122958A Rear panel <A>
32 27191143 Holder,outlet <R>
33 838430088 3TTB+8B(BC),Self-tapping screw
51 27212368 Front panel <D>
27212369 Front panel <B><P>
27212370 Front panel <S>
27212371 Front panel <B><A/T>
27212372 Front panel <G>
52 28135244 Badge <B>
28135245 Badge <G/S>
53
54
838430088
29110111
3TTB+8B(BC),Self-tapping screw
Cloth tape
55 223024 AC238,Isolated plate
56 260208 Wire tie
F6901, 252198 or 8A-UL or
F6902 252261 8A-T/UL-ST2,Fuse <D>
252099 8A-EAK,Fuse <O>
F901 252166 or 6.3A-UL/T-237 or
252260 6.3A-T/UL-ST2,Fuse <D/T/A/R/Q>
F902 252076 or 3.15A-SE-EAK or
252242 3.15A-SE-TL250V,Fuse <O>
F903 252075 or 2.5A-SE-EAK or
252241 2.5A-SE-TL250V,Fuse <O>
P101 2047151512 NCFC7-151512,Flexible flat cable
P7001 2045102012 NCFC5-102012,Flexible flat cable
P7503 2047081012 NCFC7-081012,Flexible flat cable
P901 253332HIT or AS-UC-2 or
253333VOL AS-UC-2,Power supply cord <D>
253197HIT AS-SAA,Power supply cord <A>
253233KAW AS-CEE-2,Power supply cord <P/T/K>
253198HIT AS-BS,Power supply cord <Q>
253337HIT or AS-CCEE or
253338VOL AS-CCEE,Power supply cord <R>
P902A 25052665 NSCT-2P2561,AC outlet <K>
Q6050~ 2203633, KTD1047-O,
Q6054 2203634, KTD1047-Y,
2203653, MN100S-O,
2203654 or MN100S-Y or
2203656 MN100S-P,Transistor
Q6060~ 2203623, KTB817-O,
Q6064 2203624, KTB817-Y,
2203643, MP100S-O,
2203644 or MP100S-Y or
2203646 MP100S-P,Transistor
REF.NO.
PART NO.
DESCRIPTION
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
*
*
*
*
*
*
*
*
*
*
TX-SR500/E
EXPLODED VIEW-PARTS LIST
TX-SR500/E
5
