IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS -35
Q8001 : SII504 (I/P Video Converter)
TX-SR674/674E/8467
Signal Group
Signal Name
Notes
Type
Description
Reset /Reset 5V/H In Hardware Reset.
Test Test[1:0] 5V/PD In
Production hardware test support.
PuPdDis 5V In Internal pullup and pulldown disable test
function. Connect to ground for normal
operation.
Power AVDD Pwr
1.8V Analog Power for PLL. (Qty: 1)
ARTN Pwr
Analog Return for PLLs. (Qty: 1)
VDDCore Pwr
1.8V Core Power. (Qty: 11)
GNDCore Pwr
Digital Ground for Core Power. (Qty: 12)
VDDIO Pwr
3.3V I/O Power. (Qty: 11)
GNDIO Pwr Digital Ground for I/O Power. (Qty: 18)
TERMINAL DESCRIPTION (5/5)
