14 OPAL-RT Technologies OP5700 User Manual
Installation
Cabling Instructions
INSTALLATION
BASIC INSTALLATION
Follow this simple installation procedure. Make sure to respect proper grounding,
1. Place the OP5700 on a shelf, desktop, or install in a traditional rack
2. Connect the power cable to the nearest power outlet
3. Connect the ground screw as described in the “CONNECTING THE GROUND SCREW” section
below
4. Connect the blue RJ45 cable to the Ethernet port on the OP5700 and connect to the same network
used by the host PC. Refer to the “Cabling Instructions” and the System Description document
delivered with your simulator to locate the connector to be used.
OPAL-RT strongly recommends the use of anti-static wrist straps whenever handling any electronic
device provided by OPAL-RT. Damage resulting from electrostatic charges will not be covered by the
manufacturer’s warranty.
Disconnect power before servicing.
The OP5700 may be subjected to EMI when installed in proximity to other devices. Make sure to
connect the OP5700 ground to the rack to prevent any EMI related damage to the simulator.
CABLING INSTRUCTIONS
CONNECTING RJ45 MONITORING CABLES
The OP5700 simulator offers quick, single-ended connections, through RJ45 and mini BNC connectors,
to any monitoring device (i.e. oscilloscope, etc.). These mini-BNC jacks let you monitor 4 channels
individually. Simply follow these instructions (as illustrated in Figure 5):
CAUTION
The monitoring board has a gain of 0.1 to allow a broader range of signals to be read.
Oscilloscopes must be adjusted with a gain of 10 to compensate and ensure accurate
readings.
Only connect RJ45 cables from upper section (A) monitoring jacks to lower section monitoring
panel (B, as shown). Connecting any other cable or device may result in damage to the
equipment.
