OP5700 User Manual OPAL-RT Technologies 7
Receiving and Verification
Standard Hardware
RECEIVING AND VERIFICATION
After opening the package, remove the equipment and components. Make sure that all the items
described in “Standard Hardware” are actually in the box and are undamaged.
STANDARD HARDWARE
The OP5700 real-time simulator includes the following basic hardware:
Item Description Part Number Qty
OP5700 Hardware chassis with real-time computer and FPGA 1
System integration
binder
RT-LAB or HYPERSIM software CD
O/S CD
Delivery CD (test model(s), system documentation, software licenses,
hardware documentation, additional software)
N/A 1
BNC to mini BNC
cables
2 m (6 ft 6”) adapter cables for mini-BNC to BNC. 75 Ohms simplex T00-0719 4
RJ45 cables (5) 61cm (24”) RJ45 cables BLACK
61cm (24”) RJ45 cables GREEN
61cm (24”) RJ45 cables RED
61cm (24”) RJ45 cables WHITE
305cm (120”) RJ45 cable BLUE
T00-0723
T00-0726
T00-0725
T00-0724
T00-0817
5
Power cable 1.83 m (6’) power cord, black (10A 125V) (cable varies according to
destination country)
T00-0833 1
Screw terminal board DB37 male slim breakout board (1 per bank of 16 channels) T00-4069 1
Loopback kit Provides access to quick testing and troubleshooting:
Loopback DB37 board
Flat cable
Power cable
126-0361
113-0737
113-0799
1
USBA to USBB cable 1.83m (6 ft) black USB 2.0 T00-0850 1
Screws, rubber feet Extra parts, if needed N/A
Table 1: Standard hardware list
Optional Hardware
Item Description Part Number
MUSE transceiver Avago AFBR-57R5APZ T00-0315
MUSE cable LC-LC multimode 850nm optical fiber T00-0782
