OP5700 User Manual OPAL-RT Technologies 9
Introduction
Standard Hardware
The figure below illustrates the simulator architecture.
Signal conditioning
modules
Carrier Board
Upper section
interfaces
Lower section
target computer
Figure 1: OP5700 simulator architecture
!
The image shown above is used to illustrate the layered and exible product architecture. Customers
should not open the chassis unless under the strick guidance of Technical Support.
