175Driving and operation
Picture no: 18338s.tif
Fit the tail lamps
First remove the rear (1), then the front (2)
tail lamp from the recesses.
Picture no: 18339s.tif
Open out the bulb holder on the back of
the tail lamp all the way.
Picture no: 18340s.tif
Push the clamping lever down and push
the bulb holder into the retainer until it hits
the stop.
Perform this procedure for both tail lamps.
