216 Self-help, vehicle care
Picture no: 18129s.tif
Adaptive Forward Lighting
system 3
Headlamp system has separate systems
for dipped beam 1 (outer bulbs) and main
beam 2 (inner bulbs). The cornering light is
also located behind the cover for the main
beam.
Due to the complexity of the procedure,
bulb changes should be carried out by a
workshop.
Picture no: 18134s.tif
Dipped beam
1. Open bonnet and engage support.
2. Disengage wire clip and remove cover.
Picture no: 18374s.tif
3. Press base upwards and remove from
reflector.
