217Self-help, vehicle care
Picture no: 17270t.tif
4. Detach plug connector from bulb.
5. Insert new bulb in reflector so that the
locating tab of the bulb holder aligns
with the reflector recess. Attach the bulb
holder so that the locating tab is on the
side.
6. Engage bulb.
7. Attach connector to bulb.
8. Put on cover and engage wire clip.
Picture no: 18130s.tif
Main beam
1. Open bonnet and engage support.
2. Rotate the main beam headlamp cap
anticlockwise and remove.
Picture no: 18379s.tif
3. Detach plug connector from bulb.
