226 Self-help, vehicle care
Picture no: 17298t.tif
2. Remove bulb housing downward, taking
care not to pull on the cable.
3. Lift flap and disconnect plug from bulb
socket.
Picture no: 17299t.tif
4. Rotate bulb holder to left and
disengage.
5. Remove bulb from socket.
6. Insert new bulb.
7. Insert bulb socket into bulb housing and
engage by rotating clockwise.
8. Connect plug to bulb socket.
9. Insert and engage bulb housing.
Picture no: 18365s.tif
Courtesy lamps
Front courtesy lamp
1. Disengage and remove lens at the
position located in the illustration using a
screwdriver.
2. Remove bulb from socket.
3. Insert new bulb.
4. Mount lens and engage in position.
