227Self-help, vehicle care
Picture no: 17300t.tif
Front courtesy lamp with reading lamps 3
1. Disengage lens by hand at location
illustrated in figure, press it downward
slightly and remove at a downward
angle.
2. Remove bulb from socket.
3. Insert new bulb.
4. Mount lens and engage in position.
Rear courtesy lamps 3,
rear reading lamps 3
Have bulb replacement carried out by a
workshop.
Picture no: 17301t.tif
Glove compartment lighting, luggage
compartment lighting, footwell lighting 3
1. Prise the lamp out with a screwdriver.
Picture no: 17302t.tif
2. Press bulb slightly towards spring clip
and remove.
3. Insert new bulb.
4. Insert lamp in opening and engage in
position.
Instrument illumination, Information
display illumination 3
Have bulb replacement carried out by a
workshop.
