184 Driving and operation
Towing equipment 3
Only use towing equipment that has been
approved for your vehicle. Ask a workshop
to retrofit towing equipment. It may be
necessary to make changes that affect the
cooling system, heat shields or other
equipment.
Mounting dimensions of towing equipment
3 269.
Stowage of coupling ball bar
The coupling ball bar is stowed in a bag in
the spare wheel well and secured to the
lashing eyes in the luggage compartment
3 187.
Picture no: 18389s.tif
Fitting the coupling ball bar
Push both bolts inwards and remove the
cover on the bumper.
Picture no: 18390s.tif
Fold down socket. Pull sealing plug out of
coupling ball bar opening. Place cover and
coupling ball bar in luggage compartment.
Caution
The coupling ball bar is to be removed
when not towing.
