177Driving and operation
Picture no: 18344s.tif
Remove the pedal crank mounts from the
pedal crank recesses.
Picture no: s0014629.tif
Adapting the Flex-Fix system to a bicycle
With the rotary lever on the pedal crank
recess, roughly adapt the adjustable pedal
crank unit to the protrusion of the pedal
crank.
If the bicycle has straight pedal cranks,
unscrew the pedal crank unit all the way
(position 5), see illustration.
Picture no: s0014630.tif
If the bicycle has cranked pedal cranks,
screw in the pedal crank unit all the way
(position 1), see illustration.
