179Driving and operation
Picture no: 18350s.tif
Attaching a bicycle to the Flex-Fix system
Put on the bicycle. The pedal crank here
must be placed in the pedal crank recess
opening as shown in the illustration.
Picture no: 18351s.tif
Insert pedal crank mount into outer rail of
each pedal crank recess from above and
slide downwards as far as it will go, see
figure 18454 S.
Picture no: 18454s.tif
Attach the pedal crank by rotating the
attachment screw on the pedal crank
mount.
